Industrial Valves
Precision-engineered valves with advanced lining materials for superior corrosion resistance and reliable fluid control in demanding industrial applications.
Lining Material Options
Select the right lining material for optimal chemical compatibility and performance.
PTFE Lined
Polytetrafluoroethylene - The standard for chemical resistance
PFA Lined
Perfluoroalkoxy - Superior high-purity performance
FEP Lined
Fluorinated Ethylene Propylene - Excellent chemical barrier
PP Lined
Polypropylene - Cost-effective chemical resistance
PVDF Lined
Polyvinylidene Fluoride - High purity, high temperature
Valve Types
Available in multiple configurations
Why Choose Our Valves
Engineered for reliability and performance in the most demanding applications.
Superior Corrosion Protection
Full lining coverage with no metal contact with process media, ensuring maximum service life.
Precision Flow Control
Accurate throttling and shut-off capabilities with minimal pressure drop across the valve.
Low Maintenance Design
Robust construction with replaceable components for extended service intervals.
Technical Specifications
Comprehensive specifications for all valve types and lining materials.
Standard Specifications
| Parameter | PTFE/PFA/FEP | PP | PVDF |
|---|---|---|---|
| Temperature Range | -20°C to +180°C | 0°C to +80°C | -20°C to +120°C |
| Max Pressure (bar) | 16 | 10 | 16 |
| Body Material | Cast Iron / Carbon Steel / SS316 | Cast Iron / Ductile Iron | Cast Iron / Carbon Steel / SS316 |
| Size Range | DN15 - DN600 | DN25 - DN300 | DN15 - DN400 |
| Connection Types | Flanged (ANSI/DIN/JIS) | Flanged / Threaded | Flanged (ANSI/DIN/JIS) |
| End Connection Standards | ANSI 150, DIN PN10/16, JIS 10K | ANSI 150, DIN PN10 | ANSI 150, DIN PN10/16, JIS 10K |
Chemical Compatibility Guide
| Chemical / Fluid | PTFE/PFA/FEP | PP | PVDF |
|---|---|---|---|
| Sulfuric Acid (Conc.) | Excellent | Limited | Excellent |
| Hydrochloric Acid | Excellent | Good | Excellent |
| Nitric Acid | Excellent | Limited | Good |
| Sodium Hydroxide (Caustic) | Excellent | Good | Excellent |
| Organic Solvents | Excellent | Good | Good |
| Chlorinated Solvents | Excellent | Not Recommended | Good |
| Deionized Water | Excellent | Good | Excellent |
* Torque values are approximate and may vary based on operating conditions and media.
Valve Types Available
Choose from our comprehensive range of valve configurations.
Ball Valves
Full port and reduced port designs. Ideal for on/off control with minimal pressure drop.
Butterfly Valves
Wafer and lug types. Compact design for flow regulation and isolation.
Check Valves
Swing and lift types. Prevents reverse flow in piping systems.
Diaphragm Valves
Weir and straight types. Excellent for slurry and abrasive media.
Available Valve Models
Explore our comprehensive range of industrial valves in various configurations.
PFA/FEP Ball Check Valves
PFA/FEP Lined Ball Check Valves are corrosion-resistant, non-return valves designed to prevent backflow in highly corrosive chemical applications.
View Specifications
PFA/FEP Butterfly Valves
PFA/FEP Lined Butterfly Valves offer excellent corrosion resistance for handling aggressive chemicals, ensuring tight shutoff and smooth flow control in chemical process systems.
View Specifications
PFA/FEP Diaphragm Valves
PFA/FEP Lined Diaphragm Valves are corrosion-resistant flow control valves designed for safe and leak-proof handling of aggressive and toxic chemicals in process industries.
View Specifications
PFA/FEP Plug Valves
PFA/FEP Lined Plug Valves are quarter-turn, corrosion-resistant valves designed for safe shut-off of aggressive and hazardous fluids in chemical processing systems.
View Specifications
PP/PVDF Valves
PP and PVDF Valves are corrosion-resistant plastic valves designed for safe and efficient flow control of aggressive chemicals, acids, and industrial fluids.
View SpecificationsIndustry Applications
Trusted across industries for reliable fluid control and corrosion resistance.
Chemical Processing
Water Treatment
Oil & Gas
Pharmaceutical
Food & Beverage
Power Generation
Mining & Minerals
Pulp & Paper
Frequently Asked Questions
Find answers to common questions about our industrial valves.
What is the difference between PTFE, PFA, and FEP linings?
PTFE is the standard for chemical resistance with good temperature range. PFA offers higher purity and better mechanical properties at higher temperatures. FEP provides similar chemical resistance with slightly lower temperature capability but better flow characteristics during lining application. All three are suitable for aggressive chemical service.
When should I choose PP or PVDF over fluoropolymer linings?
PP (Polypropylene) is a cost-effective option for less aggressive chemicals at moderate temperatures (up to 80°C). PVDF offers excellent chemical resistance and higher temperature capability (up to 120°C) than PP, making it suitable for stronger acids and chlorinated environments. For the most aggressive chemicals at high temperatures, PTFE/PFA/FEP are recommended.
What actuation options are available?
Our valves are available with manual handwheel, lever operation, pneumatic actuators (double acting and spring return), and electric actuators. All actuation options can be integrated with positioners, limit switches, and solenoid valves for automated control systems.
What are the pressure and temperature ratings?
Pressure ratings depend on valve size and lining material. Standard pressure rating is PN10/16 (up to 16 bar). Temperature ranges: PTFE/PFA/FEP: -20°C to +180°C, PVDF: -20°C to +120°C, PP: 0°C to +80°C. Higher temperature options available upon request.
Are these valves suitable for sanitary applications?
Yes, we offer FDA-compliant versions with PTFE/PFA linings and polished stainless steel bodies for pharmaceutical, food, and beverage applications. Sanitary connections including tri-clamp, DIN, and SMS are available.
What is the typical lead time?
Standard valves with PTFE/PP/PVDF linings are typically available within 2-3 weeks. Special materials, custom configurations, or actuated valves may require 4-6 weeks. Contact our sales team for specific delivery timelines.
